Ultimate Electrical Fault Analysis in Electrical Engineering:
Ultimate Electrical Fault Analysis in Electrical Engineering:
Original price was: £425.£29Current price is: £29. ex Vat
Take This Course OR
1 Year Access
Intermediate
1 Students -
11 hours, 59 minutes
Overview
Empower your career journey with our in-demand course: Ultimate Electrical Fault Analysis in Electrical Engineering:
Boost your proficiency and propel your career forward with our meticulously crafted course, designed to be your ultimate guide to professional development. Our super-accessible modules break down complex topics into bite-sized, easy-to-understand lessons, filling your knowledge gaps and equipping you with real-world, practical skills.
Seeking career advancement and application of your skills? You’ve found the right place. This Ultimate Electrical Fault Analysis in Electrical Engineering: is your exclusive passport to unlocking your full potential.
Enroll today and enjoy:
- 100% online flexibility: Learn at your own pace, from anywhere in the world.
- Expert support: We're by your side throughout your journey, providing guidance and assistance.
- Comprehensive curriculum: Dive deep into relevant topics aligned with industry standards.
- Practical focus: Apply your learnings to real-world scenarios and situations.
This sought-after course is your key to a successful and lucrative career. Don’t miss out on this transformative opportunity. Enroll now and take your professional life to the next level!
Course design
The course is delivered through our online learning platform, accessible through any internet-connected device. There are no formal deadlines or teaching schedules, meaning you are free to study the course at your own pace.
You are taught through a combination of
- Video lessons
- Online study materials
Exam & Retakes
It is to inform our learners that the initial exam for this online course is provided at no additional cost. In the event of needing a retake, a nominal fee of £9.99 will be applicable.
Certification
Upon successful completion of the assessment procedure, learners can obtain their certification by placing an order and remitting a fee of £9 for PDF Certificate and £15 for the Hardcopy Certificate within the UK ( An additional £10 postal charge will be applicable for international delivery).
Course Curriculum
| Fault Analysis Promo | |||
| Fault Analysis Promo | 00:03:00 | ||
| Section 01: Symmetrical Faults | |||
| What Does a Fault Mean | 00:06:00 | ||
| What Does Overloading Mean | 00:07:00 | ||
| Fault Due to Wrong Operation in Electrical System | 00:04:00 | ||
| Types of Electrical Faults According to Number of Phases | 00:07:00 | ||
| Symmetrical and Unsymmetrical Faults in Power System | 00:09:00 | ||
| Difference between Earth Fault and Phase Fault | 00:02:00 | ||
| Classification of Faults According to Time | 00:02:00 | ||
| Equations and Phasor Diagram for a Healthy Balanced System | 00:31:00 | ||
| Phasor Diagram of Three Phase to Ground Fault | 00:08:00 | ||
| Phasor Diagram of Single Line to Ground Fault | 00:03:00 | ||
| Phasor Diagram of Line to Line Fault | 00:04:00 | ||
| Phasor Diagram of Double Line to Ground Fault | 00:02:00 | ||
| Open Circuit Fault in Electrical Systems | 00:13:00 | ||
| Current and Voltage Waveforms in Case of Fault Occurrence | 00:10:00 | ||
| Representation of Electrical Components and Per Unit System | 00:16:00 | ||
| Some Important Notes | 00:04:00 | ||
| Example 1 on Per Unit System | 00:20:00 | ||
| Example 2 on Per Unit System | 00:19:00 | ||
| Different Reactance of Machine During Fault Occurence | 00:08:00 | ||
| Thevenin Methods and Steps for Fault Analysis of Symmetrical Faults | 00:25:00 | ||
| Example 1 on Symmetrical Fault Analysis | 00:22:00 | ||
| Example 2 on Symmetrical Fault Analysis | 00:14:00 | ||
| Example 3 on Symmetrical Fault Analysis | 00:13:00 | ||
| Example 4 on Symmetrical Fault Analysis | 00:12:00 | ||
| Section 02: Unsymmetrical Faults | |||
| Introduction to Unsymmetrical Faults | 00:06:00 | ||
| Conversion of Unbalanced System into Balanced Systems | 00:21:00 | ||
| Modelling Different Components for Reactance Diagram | 00:08:00 | ||
| Example on Drawing Reactance Diagram of +ve, -ve and Zero Sequences | 00:20:00 | ||
| Steps of Solution | 00:03:00 | ||
| Equivalent Circuits for Different Fault Types | 00:15:00 | ||
| Example 1 on Unsymmetrical Faults Part 1 | 00:19:00 | ||
| Example 1 on Unsymmetrical Faults Part 2 | 00:19:00 | ||
| Example 1 on Unsymmetrical Faults Part 3 | 00:19:00 | ||
| Example 2 on Unsymmetrical Faults | 00:30:00 | ||
| Section 03: ETAP Course | |||
| Introduction to ETAP | 00:15:00 | ||
| Drawing Single Line Diagram in ETAP | 00:12:00 | ||
| Adding Ratings to Components in ETAP | 00:22:00 | ||
| Load Flow and Types of Buses | 00:05:00 | ||
| Load Flow Analysis Using ETAP | 00:19:00 | ||
| Load Flow Analysis at Different Loading Categories | 00:09:00 | ||
| Short Circuit Analysis Using ETAP | 00:14:00 | ||
| Arc Flash Studies | 00:16:00 | ||
| Arc Flash Studies Using ETAP Program | 00:17:00 | ||
| Transient Stability Using ETAP 18 | 00:23:00 | ||
| Definition of Harmonics | 00:23:00 | ||
| Harmonic Analysis Using ETAP | 00:23:00 | ||
| Harmonic Filter Using ETAP | 00:14:00 | ||
| PV System Simulation Using ETAP | 00:24:00 | ||
| ETAP Motor Acceleration Analysis – Static Motor Starting | 00:17:00 | ||
| ETAP Motor Acceleration Analysis – Dynamic Motor Starting | 00:12:00 | ||
| How to Add a Starting Method to Motor in ETAP | 00:10:00 | ||
| VFD – Variable Frequency Drive Control of Motor in ETAP | 00:09:00 | ||
| Simple Example on Load Flow Analysis Using ETAP Program | 00:11:00 | ||
| Resource | |||
| Resource – Electrical Fault Analysis Training | 00:00:00 | ||
